Artec Eva Lite
Artec EVA Lite : Affordable 3D Scanning with Unmatched Quality and Simplicity
Artec Eva Lite white light scanning system from Altem is a handheld 3D Scanner, a cost-effective alternative to the popular Artec Eva 3D scanner, offering comparable accuracy and specifications while having slight reduced functionality. Specifically, Eva Lite is designed for geometry-only tracking and capture, making it well-suited for capturing high-quality textureless 3D scans of objects with intricate and organic geometries making it a ideal 3D body Scanner
This feature along with lower 3D Scanner Price tag, Eva Lite an appealing choice for healthcare entities with limited budgets or individuals seeking a professional-grade white light scanning system without significant financial investment. Being monochromatic, it requires less computational power and can be used with more affordable computer systems, overall resulting in bringing down the 3D Scanner Price.
High Accuracy
Time-saver
Cost Effective
Why Artec Eva Lite?
Looking for a cost-effective entry point into the world of 3D scanning? The Artec Eva Lite is the solution you’ve been searching for. Designed with budget-conscious companies in mind, this scanner offers exceptional value for money, making it an ideal choice for those mindful of their 3D scanner price. While the Artec Eva Lite handheld 3D Scanner may not possess the color capture capabilities of its counterpart, the Artec Eva, it still delivers impressive results at a significantly reduced cost. With its streamlined data collection capabilities, this portable handheld scanning system captures data with minimal strain on computational resources
Even more exciting is the upgrade potential. As your budget allows for future expansion, a simple upgrade can unlock the scanner’s full functionality, providing you with expanded scanning opportunities and enhanced versatility while still keeping the overall 3D scanner price manageable.
Artec Eva Lite Features
Artec Eva Lite has geometry only tracking and capture. As a result, this affordable 3D scanner.
FAST SCANNING SPEED
16 fps
Artec EVA lite white light scanning system can Capture and simultaneously process up to an impressive two million points per second!
IMPRESSIVE 3D RESOLUTION
0.5 mm
This portable handheld 3D Scanning machine can Scan in high 3D resolution capturing geometries easily
HIGH 3D POINT ACCURACY
0.1 mm
Artec Eva Lite, handheld 3D Scanner provides high accuracy for scanning objects.
SAFE TO USE
White Light
Artec Eva Lite is a white light scanning system based on white structured light technology, making it totally safe for scanning people, as well as inanimate objects.
Artec Comparison Table
Technical specifications |
 Leo |
 Eva |
Eva Lite |
 Space Spider |
 Micro II |
|---|---|---|---|---|---|
Scanner type |
Handheld | Handheld | Handheld | Handheld | Desktop |
3D point accuracy, up to |
0.1 mm | 0.1 mm | 0.1 mm | 0.05 mm | 0.005 mm |
3D resolution, up to |
0.2 mm | 0.2 mm | 0.5 mm | 0.1 mm | 40 microns |
3D accuracy over distance, up to |
0.1 mm + 0.3 mm/m | 0.1 mm + 0.3 mm/m | 0.1 mm + 0.3 mm/m | 0.05 mm + 0.3 mm/m | - |
HD Mode |
Yes | Yes | No | N/A | N/A |
Hybrid geometry and texture tracking |
Yes | Yes | No | Yes | Yes |
Data processing algorithms |
Geometry and texture based | Geometry and texture based | Geometry based | Geometry and texture based | Geometry and texture based |
Working distance |
0.35 – 1.2 m | 0.4 – 1 m | 0.4 – 1 m | 0.2 – 0.3 m | - |
Volume capture zone |
160,000 cm³ | 61,000 cm³ | 61,000 cm³ | 61,000 cm³ | 6,000 cm³ (18.5 times larger) |
Linear field of view, H×W @ closest range |
244 × 142 mm | 214 × 148 mm | 214 × 148 mm | 180 × 140 mm | - |
Linear field of view, H×W @ furthest range |
838 × 488 mm | 536 × 371 mm | 536 × 371 mm | 30 × 21° | - |
Angular field of view, H×W |
38.5 × 23° | 30 × 21° | 30 × 21° | Yes | - |
Ability to capture texture |
Yes | Yes | No | 1.3 mp | Yes |
Texture resolution |
2.3 mp | 1.3 mp | - | 24 bpp | 13 MP |
Colors |
24 bpp | 24 bpp | - | 7.5 fps | 24 bpp |
3D reconstruction rate for real-time fusion, up to |
22 fps | 16 fps | 16 fps | 7.5 fps | - |
3D reconstruction rate for 3D video recording, up to |
44 fps | 16 fps | 16 fps | - | - |
3D reconstruction rate for 3D video streaming, up to |
80 fps | — | — | 1 mln points/s | — |
Data acquisition speed, up to |
35 mln points/s | 18 mln points/s | 2 mln points/s | 0.0002 s | 1 mln points/s |
3D exposure time |
0.0002 s | 0.0002 s | 0.0002 s | 0.0002 s | Customizable |
2D exposure time |
0.0002 s | 0.00035 s | 0.00035 s | Blue LED | Customizable |
3D light source |
VCSEL | Flashbulb | Flashbulb | White 6 LED array | RGB LED |
2D light source |
White 12 LED array | White 12 LED array | White 12 LED array | — | RGB LED |
Position sensors/strong> |
Built-in 9 DoF inertial system | — | — | USB streaming through external computer | — |
Display/touchscreen |
Integrated 5.5" half HD, CTP. Optional Wi-Fi/Ethernet video streaming to external device | USB streaming through external computer | USB streaming through external computer | On external computer | USB streaming through external computer |
Multi-core processing |
Embedded processors: NVIDIA® Jetson™ TX1 Quad-core ARM® Cortex®-A57 MPCore Processor NVIDIA Maxwell™ 1 TFLOPS GPU with 256 NVIDIA® CUDA® Cores | On external computer | On external computer | 1 × USB 2.0, USB 3.0 compatible | On external computer |
Interface |
Wi-Fi, Ethernet, SD card | 1 × USB 2.0, USB 3.0 compatible | 1 × USB 2.0, USB 3.0 compatible | — | USB 3.0 |
Internal hard drive |
512 GB SSD | — | — | Windows 7, 8, 10, 11 x64 | — |
Supported OS |
Scanning: No computer required Data processing: Windows 7, 8, 10, 11 x64 | Windows 7, 8, 10, 11 x64 | Windows 7, 8, 10, 11 x64 | Intel Core i7 or i9, 32 GB RAM, GPU with 2 GB VRAM | Windows 10, 11 x64 |
Recommended computer requirements |
Intel Core i7 or i9, 64+ GB RAM, NVIDIA GPU with 8+ GB VRAM, CUDA 6.0+ | Intel Core i7 or i9, 64+ GB RAM, NVIDIA GPU with 8+ GB VRAM, CUDA 6.0+ | Intel Core i7 or i9, 32 GB RAM, GPU with 2 GB VRAM | Intel Core i5, i7 or i9, 18 GB RAM, GPU with 2 GB VRAM | Intel Core i7 or i9, 64+ GB RAM, NVIDIA GPU with at least 3 GB VRAM, CUDA 3.5+ |
Minimum computer requirements |
HD: Intel Core i7 or i9, 32 GB RAM, NVIDIA GPU with CUDA 6.0+ and at least 4 GB VRAM SD: Intel Core i5, i7 or i9, 32 GB RAM, GPU with 2 GB VRAM A computer is needed only for data processing. Scanning does not require a computer. | HD: Intel Core i7 or i9, 32 GB RAM, NVIDIA GPU with CUDA 6.0+ and at least 2 GB VRAM SD: Intel Core i5, i7 or i9, 12 GB RAM, GPU with 2 GB VRAM | Intel Core i5, i7 or i9, 12 GB RAM, GPU with 2 GB VRAM | OBJ, PLY, WRL, STL, AOP, ASC, PTX, E57, XYZRGB | Intel Core i5, i7, or i9, 32GB RAM, GPU with 2 GB VRAM |
3D mesh |
OBJ, PLY, WRL, STL, AOP, ASC, PTX, E57, XYZRGB | OBJ, PLY, WRL, STL, AOP, ASC, PTX, E57, XYZRGB | OBJ, PLY, WRL, STL, AOP, ASC, PTX, E57, XYZRGB | STEP, IGES, X_T | OBJ, PLY, WRL, STL, AOP, ASC, PTX, E57, XYZRGB |
CAD |
STEP, IGES, X_T | STEP, IGES, X_T | STEP, IGES, X_T | CSV, DXF, XML | STEP, IGES, X_T |
Measurements |
CSV, DXF, XML | CSV, DXF, XML | CSV, DXF, XML | AC power or external battery pack | CSV, DXF, XML |
Power source |
Built-in exchangeable battery, optional AC power | AC power or external battery pack | AC power or external battery pack | 190 × 140 × 130 mm | AC power |
Dimensions, HxDxW |
231 × 162 × 230 mm | 262 × 158 × 63 mm | 262 × 158 × 63 mm | 0.8 kg / 1.8 lb | 396 × 405 × 337 mm |
Weight |
2.6 kg / 5.7 lb | 0.9 kg / 2 lb | 0.9 kg / 2 lb | 12 kg |
Enough Talk Let’s Build Something Together
Industries
Artec Portable 3D Scanners are used in streamlining, developing, and customizing a wide range of industries.
Product design
Customisation
3D documentation
Quality Control
Rapid Prototyping
Orthopedics
Orthotics & Prosthetics
Plastic Surgery
Custom Wheelchairs
Research
Training
Online Museums
Forensics
Archaeology
Architecture
CGI
Fashion
Captured with Artec Eva Lite 3D scanner
Creating highly accurate 3D models of objects with various textures, sizes and geometries.
Scan The Object
Fuse & Optimize
Texturize & Export
Artec Studio : Effortless and Speedy 3D Data Post-Processing Solutions
Experience the extensive array of post-processing tools available in our cutting-edge 3D data processing photogrammetric software, widely regarded as the most comprehensive solution in the market.
Factory bundled along with the 3D Scanning machine, it allows you a seamless 3D Scanning workflow with our new Autopilot mode, designed to cater to users of all levels of expertise. This intelligent mode guides you effortlessly through every step of the post-processing process, automatically selecting the optimal algorithms to transform your data into a flawless 3D model, right in front of your eyes.
Alternatively, you can take full command this white light scanning system and process data process using the powerful and advanced features of Manual mode. With a diverse range of tools at your disposal, you can create high-quality 3D models / stl file tailored for export to CAD, 3D printing, and various other applications.
Scan-to-CAD features for inspection and engineering
Get the best results effortlessly with the smart Autopilot mode
Photorealistic texture for your scan data
